Bidirectional DC-DC Converter
-
Bidirectional Power Flow: Allows both charging and discharging of energy storage devices (e.g., batteries), making it ideal for energy storage and balancing systems.
-
High Efficiency: Provides high energy conversion efficiency (up to 98%), ensuring minimal energy loss during power transfer.
-
Wide Input/Output Voltage Range: Can be configured for different input and output voltages, making it versatile for various applications.
-
Compact and Lightweight: Small size and low weight, suitable for space-constrained applications such as electric vehicles and solar energy systems.
-
Comprehensive Protection: Includes overvoltage, overcurrent, and thermal protection to ensure safe and reliable operation.
Certification：
| Attribute | Description |
|---|---|
| Input Voltage | 10V - 60V (depends on specific model) |
| Output Voltage | 10V - 60V (configurable depending on model) |
| Rated Power | 100W - 1000W (depends on specific model) |
| Efficiency | 95% - 98% (high efficiency for optimal power conversion) |
| Control Method | Digital or PWM-based control for precise regulation |
| Protection Features | Overvoltage, overcurrent, short circuit, thermal protection |
| Operating Temperature | -20°C to +60°C (ambient temperature range for optimal operation) |
| Communication Interface | Optional interfaces (RS485, CAN bus, or I2C) for remote monitoring and control |
| Weight | 0.5kg - 3kg (varies based on model and power rating) |
| Dimensions | Varies by model (e.g., 150mm x 100mm x 50mm) |
FAQ
With automotive-grade A-class cells and intelligent BMS synergy, CIC batteries deliver 3X higher energy density than lead-acid batteries.
Extended Range: Golf cart range increases from 40km to 100km per charge (2.5X improvement)
Decade-long Durability: 6000+ deep cycles (≈10 years) with 8X total range over lifespan
Stable Output: BMS maintains power variance within 5% from 100% to 20% SOC
Our 24V-120V Full-range Compatibility Solution offers:Plug & Play: Direct replacement for 24V/48V/72V systems without interface modification
Smart Integration: CAN bus adapter harness included (compatible with Curtis/Lester controllers)
Custom Design: Battery packs optimized for your motor’s peak power (provide specifications)
Our triple-layer protection aligns with global safety frameworks:Cell Monitoring: ±5mV voltage accuracy (UL 1973 compliant) with 6hr early warning
System Protection: BMS achieves 50ms fault isolation (2X faster than lead-acid systems)
Structural Integrity: IP67 enclosure passes 1m multi-axis drop test (IEC 62133-2 aligned)
Our 3D Precision Customization Service includes:
Structural Design: L/U/Stepped shapes with 15mm bending radius (EN 50548 compliant)
Optional OTA module for remote adjustment of: SOC balancing & Charging temp thresholds & Discharge curves
Environmental Adaptation: IP68/IP69K protection with anti-vibration mounts
We provide a three-tier after-sales response system:
24/7 Remote Diagnosis
Submit BMS error codes to resolve 80% of issues remotely.
3-Year Warranty
Free replacement of components for quality-related issues within 3 years.
Engineer Technical Support
On-site service available in Europe, the Middle East, and Southeast Asia. Free technical support from engineers can be requested for unresolved issues.
