80V 690Ah Lithium Forklift Battery

  • Nominal Voltage: 80V
  • Nominal Capacity: 690Ah
  • Stored Energy: 55.2 kWh
  • Dimension (L×W×H) In Inch: 39.72 x 32.76 x 29.49 inch
  • Dimension (L×W×H) In Millimeter: 1009 x 832 x 749 mm
  • Weight lbs. (kg) No Counterweight: 2705 lbs   (1227 kg)
  • Life Cycle: >3500 cycles
  • IP Rating: IP65
  • Lead Acid Model (BCl Number): 40-125-11

Certification：

CONTACT US
Nominal Voltage  80V Nominal Capacity 690Ah
Stored Energy 55.2 kWh Dimension(L×W×H)

For Reference

 39.72 x 32.76 x 29.49 inch

(1009 x 832 x 749 mm)
Weight lbs.(kg)

No Counterweight

 2705 lbs . (1227 kg) life Cycle >3500 cycles
Continuous Discharge 420A Maximum Discharge 700 A (30s)
Charge -4°F~131°F (-20°C ~ 55°C) Discharge -4°F~131°F ( -20°C ~ 55°C)
Storage (1 month) -4°F~113°F (-20°C~45°C) Storage (1 year) 32°F~95°F ( 0°C ~ 35°C)
Casing Material Steel IP Rating IP65
Fast charge & No “memory” effect
0 maintenance, 3 years warranty.
10 years lifespan, 3500+ cycle life.
Lower power force start, 13 protection, power display.
Can be connected in any parallel, multiple parallels or multiple series.
Zero daily maintenance and no battery room required
Lifepo4 Battery For Golf Cart
Lifepo4 Battery For Forklifts
Lifepo4 Battery For AWPS
Lifepo4 Battery For FCMS
Marine Energy Storage System
Residential Energy Storage System
RV Energy Storage System
Truck ALL-Electric APU

FAQ

How much range improvement can CIC lithium batteries provide for low-speed vehicles compared to traditional lead-acid batteries?

With automotive-grade A-class cells and intelligent BMS synergy, CIC batteries deliver 3X higher energy density than lead-acid batteries.

Extended Range: Golf cart range increases from 40km to 100km per charge (2.5X improvement)

Decade-long Durability: 6000+ deep cycles (≈10 years) with 8X total range over lifespan

Stable Output: BMS maintains power variance within 5% from 100% to 20% SOC

Is your voltage system compatible with legacy lead-acid battery vehicles? What components need replacement?

Our 24V-120V Full-range Compatibility Solution offers:Plug & Play: Direct replacement for 24V/48V/72V systems without interface modification

Smart Integration: CAN bus adapter harness included (compatible with Curtis/Lester controllers)

Custom Design: Battery packs optimized for your motor’s peak power (provide specifications)

How is battery safety ensured? Does it meet industry standards?

 Our triple-layer protection aligns with global safety frameworks:Cell Monitoring: ±5mV voltage accuracy (UL 1973 compliant) with 6hr early warning

System Protection: BMS achieves 50ms fault isolation (2X faster than lead-acid systems)

Structural Integrity: IP67 enclosure passes 1m multi-axis drop test (IEC 62133-2 aligned)

Can you customize battery packs for unique vehicle structures?

Our 3D Precision Customization Service includes:

Structural Design: L/U/Stepped shapes with 15mm bending radius (EN 50548 compliant)​

Optional OTA module for remote adjustment of: SOC balancing & Charging temp thresholds & Discharge curves

Environmental Adaptation: IP68/IP69K protection with anti-vibration mounts

How to get quick repair service for battery failures? Is global warranty available?

 We provide a three-tier after-sales response system​​:

24/7 Remote Diagnosis​​

Submit BMS error codes to resolve 80% of issues remotely.

3-Year Warranty​​

Free replacement of components for quality-related issues within 3 years.

Engineer Technical Support​​

On-site service available in Europe, the Middle East, and Southeast Asia. Free technical support from engineers can be requested for unresolved issues.
